Pa3X Specifications Chart

Keyboard:

61-key with velocity and aftertouch

76 semi-weighted keys with velocity and aftertouch



System

OPOS (Objective Portable Operating System)

RX (Real eXperience)

DNC (Defined Nuance Control)

Natural Ambience Drums Sound Technology

Multitasking, Load while play feature

Upgradable Operating System

Self-Refresh Battery for PCM data



Tone Generator

KORG EDS (Enhanced Definition Synthesis) sound generator:

120 Voices, 120 Oscillators

Filters with Resonance

Three band EQ for each track



Effects

Up to 8 Stereo Digital Multi-Effects block system

140 Effects types plus VOCODER

Final Mastering Effects by WAVES

(MaxxEQ™, MaxxBass™, MaxxTreble™, MaxxStereo™, MaxxVolume™)

New Voice Processor Technology by TC-Helicon® with 7 Effects:

Four-part Harmonizer, Double, µMod, Reverb, Delay, Filter, HardTune, Pitch Correction plus Compressor, EQ, Gate (Adaptive Mic Setting on the Mic input)



Sounds / Drumkits

More than 1100, including Stereo Piano and GM Level 1 & 2 compatible sounds; more than 90 Drum Kits

User area: 512 Sounds, 128 Drum Kits

Defined Nuance Control (DNC) Technology

Real Drum Ambience

Digital Drawbars: 9 Footages

Realtime controls: Assignable Sliders

Full editing of Sounds and Drum Kits

Sampling: Record, Edit, Time Slice, Compression Tool, Load/Import of Korg, Wav, AIFF and Akai files; Export of Wav and AIFF files

PCM RAM Memory: 128 MB standard (equivalent to 256 MB linear data), expandable up to 256 MB (equivalent to 512MB linear data) with the optional EXB-M256 memory expansion board



Styles

More than 400 preloaded Styles, freely reconfigurable

1200 available Style locations including the Favorite banks

Eight Style tracks, 4 Single Touch Settings, 4 Pads and one Style Performance per Style Guitar Track 2 mode, Parallel and Fixed NTT

Compatible with old “i-Series” and Pa series Style format

Style Record with Step Record, Track and Event Edit functions

Style controls: 3 Intros, 4 Variations, 4 Fills, Break, 3 Endings, Synchro Start/Stop, Tap Tempo/Reset, Fade In/Out, Bass Inversion, Auto Fill, Manual Bass, Tempo Lock, Memory, Accompaniment/Real Time Track Balance Volume, Accompaniment Mute, Drum Mapping, Snare & Kick Designation, Single Touch



Chord Sequencer

Realtime Style Chord Sequencer Recorder



Performance / STS

512 Realtime Performance locations

STS: Memorize Realtime tracks and Voice Processor settings, up to 4 x 1200 Styles, up to 4 x SongBook entries



Realtime tracks

Four Keyboard tracks (Upper 1, 2, 3, Lower) with dedicated on/off and sound select buttons



Song Play

Patented XDS Crossfade Dual Sequencer Player (Supported formats: MID, MID+G, KAR, MP3 + lyrics, MP3+G)

2 Players with separate Select, Start/Stop, Home, Rewind and Fast Forward controls X-Fader Balance control

Lyrics, Score, and Chord data can be displayed on screen, or on external video monitor (with VIF4 option installed)

Markers

Jukebox function



Mp3 Player / Recorder

Double Mp3 Player and Mp3 Recorder

Two Mp3 files can be played simultaneously in Song Play Mode

Real Time Transpose (+6/-5 semitones)

Tempo change (±30%)

Advanced Vocal Remover Record MP3 files including Styles, SMF, Real Time Tracks, Pads, Microphone and Effects

Audio Chord detection for Vocal Harmony



Sequencer

Quick Record (Backing Sequence)

Multitrack and Step Record functions – Full-featured sequencer

16 tracks; Up to 200,000 events

SMF native format



SongBook

Fully programmable music database, based on Styles, SMF, Karaoke, MP3 with automatic selection of Style Play and Song Play modes

User-definable custom lists

Filtering and Ordering options



Compatibility

“i-Series” models: Styles

Pa series: Style, Performance, Program/Sound, Song, SongBook, Pad



Multi Pad

4 Assignable Pads + Stop Button – Pad Record function



Help System

Hypertextual, Contextual, Multilingual



General Controls

Master Volume, Real Time-Acc/Seq Balance Volume, Ensemble, Octave Transpose, Master Transpose, Style Change, Quarter Tone and Arabic Scale memorized inside Performance/STS – Realtime controllers: Joystick (pitch + modulation), Ribbon Control, 8 Assignable Sliders, MP3 Volume, Mic Volume, Mic Harmony/Double Vol., Mic Reverb/Delay Vol., 3 Assignable Switches, Tempo +/-, Dial, Up/+, Down/- – Search Function



Control Inputs

Damper Pedal (support half-pedaling with optional DS-1H pedal), Assignable Pedal/Switch, EC-5 (Programmable Multi-Switches)



Analog Outputs

Unbalanced/Balanced Jack Left/Mono, Right/Mono, Out 1, Out 2, Headphones (in the front panel)



Digital Outputs

S/P DIF (48 kHz – coaxial), mirroring the Main Stereo Outputs



Line Inputs

2 Unbalanced/Balanced Jack Left/Mono, Right/Mono



Microphone Input

Combo XLR balanced with Gain control (15 to 50 dB) and switchable Phantom Power



MIDI

In, Out, Thru; standard Midi connectors

USB to Midi using the USB Device port

Individual track assignment

8 user definable MIDI Setups



USB

2 USB Host Front/Rear (2.0 Hi Speed) and 1 USB Device Rear (1.1 Full Speed) connections



Hard Disk / Mass Storage

Standard 4 GB memory USB

Optional 2.5″ SATA Hard Disk Driver (61-key)

Standard internal 2.5″ SATA Hard Disk Drive (76-key)



DVD-CD Player / Floppy Disk

Optional using standard USB DVD/CD/FD Drives connected via USB Host ports



Display

Pa3X 61: Resolution: 320 x 240 pixels – TFT Color TouchView Graphic Touch Screen;

Pa3X 76: Motorized Tilt Display – Resolution: 320 x 240 pixels – TFT Color TouchView Graphic Touch Screen



Clock

Internal System Clock



Consumption

30 Watt – 50 Watt when connected with Amplification Bar (PaAS)



Dimensions (W x D x H)

980 x 366 x 145 mm / 38.58 x 14.41 x 5.71 inch without music stand (61);

1192 x 366 x 145 mm / 49.93 x 14.41 x 5.71 inch without music stand and with the display fully lowered (76)



Weight

14.7 kg / 32.4 lbs (61); 17.5 kg / 38.58lbs (76)



Accessories

Manual, AC Power Cable, Music Stand, CD-ROM



Options

PaAS Amplification System

EXB-M256 – 256 MB RAM Expansion Board

VIF4 – Video Interface Board

EXP-2 – Expression/Volume Pedal

XVP-10 – Professional Expression/Volume Pedal

EC5 – Assignable Multi-Switch Controller

DS-1H – Damper Pedal

PS-1 – Switch Pedal

Hard Disk Kit Installation Kit (61 only)



* Helicon is a registered trademark of TC-Helicon Vocal Technologies Ltd.
* MaxxAudio, MaxxEQ, MaxxBass, MaxxTreble, MaxxStereo, MaxxVolume are trademarks of Waves Audio Ltd.
* Specifications and appearance are subject to change without notice for improvement.
